Introduction to yersinia: Plague Transmission Modeling in R

Overview

The yersinia package provides a comprehensive toolkit for modeling plague transmission dynamics using stochastic simulation. Built on the robust odin.dust framework, it captures realistic biological processes including demographic stochasticity, spatial spread, and complex multi-host dynamics.

Why Stochastic Models?

Plague outbreaks exhibit high variability due to: - Small population sizes where random events matter - Environmental stochasticity in transmission rates - Spatial heterogeneity in population densities - Stochastic extinction and recolonization events

Traditional deterministic models miss these crucial dynamics that determine real outbreak patterns.

Key Features

Stochastic simulation: Demographic noise and realistic extinction/recolonization dynamics
Spatial metapopulations: Migration, local adaptation, and spatial spread patterns
Evidence-based parameters: Curated parameter sets from historical and contemporary research
Multi-host dynamics: Rat-flea cycles with optional human transmission
Comprehensive analysis: Built-in functions for R₀, outbreak metrics, spatial analysis, and visualization
Professional plotting: Phase portraits, spatial heatmaps, animations, and publication-ready figures

library(yersinia)
library(dplyr)
library(ggplot2)
library(purrr)

# Set a random seed for reproducible results
set.seed(42)

Getting Started

Your First Plague Model

The simplest way to run a plague model is with run_plague_model():

# Run a stochastic rat-flea model (single population)
results <- run_plague_model(
  years = 2,
  n_particles = 100           # Stochastic replicates for uncertainty quantification
)

# View the structured results
results
#> Plague Model Results
#> ====================
#> Model type: stochastic_single
#> Parameter set:
#> Time points: 104
#> Replicates: 100
#> Populations: 1
#> Compartments: S, I, R, N, F
#>
#> Data preview:
#> # A tibble: 52,000 × 5
#>    population compartment replicate   time value
#>  *      <int> <chr>           <int>  <dbl> <dbl>
#>  1          1 S                   1 0.0192  2500
#>  2          1 I                   1 0.0192     1
#>  3          1 R                   1 0.0192     0
#>  4          1 N                   1 0.0192     4
#>  5          1 F                   1 0.0192     0
#>  6          1 S                   2 0.0192  2500
#>  7          1 I                   2 0.0192     1
#>  8          1 R                   2 0.0192     0
#>  9          1 N                   2 0.0192     4
#> 10          1 F                   2 0.0192     0
#> # ℹ 51,990 more rows

The model returns a plague_results object with: - Tidy data format: Time-series data in long format with standardized column names - Metadata: Model type, parameters, and run information stored as attributes - Multiple replicates: Each particle represents one stochastic realization

Built-in Plotting

All results have intelligent default plotting that shows uncertainty across replicates:

plot(results)

Basic plague dynamics showing median trajectories with 95% confidence intervals

Extracting Key Information

The package provides professional analysis tools instead of manual calculations:

# Get outbreak summary statistics
outbreak_stats <- calculate_outbreak_metrics(results, compartment = "I")
summary_stats <- summarize_outbreak_metrics(outbreak_stats)

print(summary_stats)
#> # A tibble: 1 × 11
#>   population n_replicates outbreak_probability mean_peak median_peak sd_peak
#>        <int>        <int>                <dbl>     <dbl>       <dbl>   <dbl>
#> 1          1          100                    1      975.       1012.    201.
#> # ℹ 5 more variables: mean_duration <dbl>, median_duration <dbl>,
#> #   mean_time_to_peak <dbl>, peak_ci_lower <dbl>, peak_ci_upper <dbl>

Evidence-Based Parameters

Curated Parameter Sets

The package includes parameter sets from key plague research:

# Examine a parameter set
keeling_params <- load_scenario("keeling-gilligan")
keeling_params
#> 🦠 Plague Scenario (keeling-gilligan)
#> 📄  Biological parameters from Keeling & Gilligan (2000) metapopulation plague model
#> 📚 Source:  Keeling, M. J., & Gilligan, C. A. (2000)
#>
#> 🐀 Rat Population Parameters:
#>   r_r    =    5.000  # Rat population growth rate (per year)
#>   d_r    =    0.200  # Natural death rate of rats (per year)
#>   p      =    0.975  # Probability of inherited resistance
#>
#> 🦟 Flea Parameters:
#>   K_f    =    6.570  # Flea carrying capacity per rat
#>   r_f    =   20.000  # Flea reproduction rate (per year)
#>   d_f    =   10.000  # Death rate of free fleas (per year)
#>   a      =    0.004  # Flea search efficiency
#>
#> 🔬 Disease Parameters:
#>   beta_r =    4.700  # Rat infection rate from fleas (per year)
#>   m_r    =   20.000  # Infected rat mortality rate (per year)
#>   g_r    =    0.020  # Probability rat survives infection
#>
#> 👤 Human Parameters:
#>   r_h    =    0.045  # Human population growth rate (per year)
#>   d_h    =    0.040  # Natural death rate of humans (per year)
#>   beta_h =    0.010  # Human infection rate from fleas
#>   m_h    =   26.000  # Human recovery rate (per year)
#>   g_h    =    0.100  # Probability human survives infection
#>
#> ⚙️  Other Parameters:
#>   mu_r   =    0.030  # Rat movement rate (per year)
#>   mu_f   =    0.008  # Flea movement rate (per year)
#>   seasonal_amplitude =    0.200  #
#>
#> 📈 Basic Reproduction Number (R₀):  581.657 ✅ (Disease can spread)

# Compare R₀ across all parameter sets
param_sets <- c("defaults", "keeling-gilligan", "modern-estimates", "historical")

r0_comparison <- tibble(
  Parameter_Set = param_sets,
  R0 = map_dbl(param_sets, ~ calculate_R0(load_scenario(.x))),
  Source = c("Package defaults", "Keeling & Gilligan (2000)", "Contemporary estimates", "Medieval estimates")
)

print(r0_comparison)
#> # A tibble: 4 × 3
#>   Parameter_Set       R0 Source
#>   <chr>            <dbl> <chr>
#> 1 defaults          582. Package defaults
#> 2 keeling-gilligan  582. Keeling & Gilligan (2000)
#> 3 modern-estimates  685. Contemporary estimates
#> 4 historical        596. Medieval estimates

The basic reproduction number (R₀) determines outbreak potential: - R₀ > 1: Disease can spread and establish - R₀ < 1: Disease will die out without sustained transmission

Parameter Customization

Parameters can be modified at runtime without editing scenario files:

# Run model with modified transmission parameters
results_enhanced <- run_plague_model(
  scenario = "keeling-gilligan",
  beta_r = 8.0,          # Higher rat infection rate
  g_r = 0.05,            # Higher rat survival rate
  K_f = 6,               # More fleas per rat
  years = 3,
  n_particles = 80
)

# Compare outbreak metrics
enhanced_stats <- results_enhanced |>
  calculate_outbreak_metrics(compartment = "I") |>
  summarize_outbreak_metrics()

cat("Enhanced transmission outbreak probability:", enhanced_stats$outbreak_probability, "\n")
#> Enhanced transmission outbreak probability: 1

Model Architecture

Single Population: Core Dynamics

Examine the fundamental rat-flea transmission cycle:

# Focused rat-flea dynamics
results_core <- run_plague_model(
  scenario = "keeling-gilligan",
  npop = 1,
  n_particles = 60,
  years = 5
)

# Show only core compartments for clarity
plot_dynamics(results_core, compartments = c("S", "I", "R"))

Phase Space Analysis

Visualize the dynamical system in phase space:

# Create phase portrait for S-I dynamics
# Note: Advanced plotting functions are provisional and may change in future versions
plot_phase_portrait(results_core, compartments = c("S", "I"))

Phase portrait showing susceptible-infected dynamics

Multi-Host Dynamics: Rats + Humans

Include human populations in the transmission cycle:

# Model including human transmission (single population only)
results_humans <- run_plague_model(
  scenario = "historical",     # Medieval parameters for dramatic effect
  include_humans = TRUE,
  npop = 1,                   # Human models require single population
  n_particles = 60,
  years = 8
)

# Plot all compartments to show multi-host dynamics
plot_dynamics(results_humans)

Multi-host plague dynamics with humans

Human-Specific Analysis

Focus on human epidemic patterns:

# Calculate human outbreak metrics
human_metrics <- results_humans |>
  calculate_outbreak_metrics(compartment = "Ih") |>
  summarize_outbreak_metrics()

cat("Human outbreak probability:", round(human_metrics$outbreak_probability, 3), "\n")
#> Human outbreak probability: 0.967
cat("Mean peak human infections:", round(human_metrics$mean_peak, 0), "\n")
#> Mean peak human infections: 1641

Spatial Metapopulations

Multi-population models with migration reveal spatial spread patterns:

# 25-population spatial model (5x5 grid with nearest-neighbor migration)
results_spatial <- run_plague_model(
  scenario = "defaults",
  K_r = 12500,             # Total capacity distributed across populations
  npop = 25,               # Auto-configured as 5x5 grid
  n_particles = 40,
  years = 15,
  seasonal = TRUE
)

# Basic spatial dynamics
plot_dynamics(results_spatial, population = 13)  # Center population

Spatial Heat Maps (Provisional)

Visualize infection patterns across the landscape:

# Heat maps at different time points
# Note: Spatial plotting functions are experimental and may change
plot_spatial_heatmap(results_spatial, time_point = 3, compartment = "I")

Spatial distribution of infections at different time points

plot_spatial_heatmap(results_spatial, time_point = 8, compartment = "I")

Spatial distribution of infections at different time points

plot_spatial_heatmap(results_spatial, time_point = 12, compartment = "I")

Spatial distribution of infections at different time points

Animated Spatial Spread (Provisional)

Create animations showing disease spread over time:

# Create animated visualization (requires gganimate)
# Note: Animation functions are experimental and may change
anim <- animate_spatial_spread(results_spatial, compartment = "I",
                              time_points = seq(0, 15, by = 0.5))
anim

Spatial Correlation Analysis

Quantify spatial synchrony in infection patterns:

# Calculate spatial correlation matrix
cor_matrix <- calculate_spatial_correlation(results_spatial, compartment = "I")

# Visualize correlation structure
cor_data <- cor_matrix |>
  as.data.frame() |>
  tibble::rownames_to_column("pop1") |>
  tidyr::pivot_longer(-pop1, names_to = "pop2", values_to = "correlation") |>
  mutate(
    pop1_num = as.numeric(gsub("pop_", "", pop1)),
    pop2_num = as.numeric(gsub("pop_", "", pop2))
  )

ggplot(cor_data, aes(pop1_num, pop2_num, fill = correlation)) +
  geom_tile() +
  scale_fill_gradient2(low = "blue", mid = "white", high = "red",
                       midpoint = 0, name = "Correlation") +
  labs(title = "Spatial Correlation in Infection Levels",
       x = "Population", y = "Population") +
  theme_minimal()

Environmental Seasonality

Seasonal forcing drives annual epidemic cycles:

# Compare seasonal vs non-seasonal models
results_constant <- run_plague_model(
  scenario = "modern-estimates",
  seasonal = FALSE,
  years = 12,
  n_particles = 50
)

results_seasonal <- run_plague_model(
  scenario = "modern-estimates",
  seasonal = TRUE,
  years = 12,
  n_particles = 50
)

# Plot comparison using built-in function
plot_comparison(list("Constant" = results_constant, "Seasonal" = results_seasonal),
                compartment = "I")

Seasonal plague dynamics showing annual cycles

Seasonal forcing captures the annual climate-driven cycles observed in natural plague systems, where transmission peaks during favorable environmental conditions.

Advanced Analysis Toolkit

Reproduction Numbers and Invasion Analysis

Calculate R₀ to predict outbreak potential:

# R₀ comparison across scenarios
r0_analysis <- tibble(
  Scenario = c("Historical", "Modern", "High Transmission", "Poor Sanitation"),
  Parameters = list(
    load_scenario("historical"),
    load_scenario("modern-estimates"),
    load_scenario("modern-estimates", beta_r = 8.0),
    load_scenario("modern-estimates", K_f = 8.0, K_r = 4000)
  ),
  R0 = map_dbl(Parameters, calculate_R0),
  Invasion_Risk = ifelse(R0 > 1, "High", "Low")
)

print(r0_analysis[c("Scenario", "R0", "Invasion_Risk")])
#> # A tibble: 4 × 3
#>   Scenario             R0 Invasion_Risk
#>   <chr>             <dbl> <chr>
#> 1 Historical         596. High
#> 2 Modern             685. High
#> 3 High Transmission 1096. High
#> 4 Poor Sanitation   1096. High

# Visualize invasion thresholds
ggplot(r0_analysis, aes(x = reorder(Scenario, R0), y = R0, fill = Invasion_Risk)) +
  geom_col(alpha = 0.8) +
  geom_hline(yintercept = 1, linetype = "dashed", color = "red", size = 1) +
  coord_flip() +
  scale_fill_manual(values = c("High" = "coral", "Low" = "lightblue")) +
  labs(title = "Outbreak Risk Assessment",
       subtitle = "R₀ > 1 indicates potential for sustained transmission",
       x = "Scenario", y = "Basic Reproduction Number (R₀)") +
  theme_minimal()

Force of Infection Dynamics

Analyze transmission pressure over time:

# Calculate force of infection for spatial model
#foi_data <- calculate_force_of_infection(results_spatial)

# Plot force of infection for central populations
# foi_data |>
#   filter(population %in% 12:14) |>  # Central populations
#   tidyr::pivot_longer(c(lambda_h, lambda_r), names_to = "host", values_to = "foi") |>
#   ggplot(aes(time, foi, color = factor(population))) +
#   geom_line(alpha = 0.8) +
#   facet_wrap(~host, scales = "free_y",
#              labeller = labeller(host = c("lambda_h" = "Humans", "lambda_r" = "Rats"))) +
#   labs(title = "Force of Infection Over Time",
#        x = "Time (years)", y = "Force of Infection",
#        color = "Population") +
#   theme_minimal()

Professional Outbreak Metrics

Use built-in analysis functions for comprehensive outbreak characterization:

# Comprehensive outbreak analysis for spatial model
outbreak_metrics <- results_spatial |>
  calculate_outbreak_metrics(compartment = "I", threshold = 5) |>
  summarize_outbreak_metrics()

# Display key metrics
cat("Spatial Model Outbreak Summary:\n")
#> Spatial Model Outbreak Summary:
cat("================================\n")
#> ================================
cat("Outbreak probability:", round(outbreak_metrics$outbreak_probability[1], 3), "\n")
#> Outbreak probability: 0.55
cat("Mean peak infections:", round(outbreak_metrics$mean_peak[1], 1), "\n")
#> Mean peak infections: 68.4
cat("Mean outbreak duration:", round(outbreak_metrics$mean_duration[1], 1), "years\n")
#> Mean outbreak duration: 1.6 years
cat("Time to peak:", round(outbreak_metrics$mean_time_to_peak[1], 1), "years\n")
#> Time to peak: 0.3 years

Parameter Sensitivity & Model Comparison

Systematic Parameter Exploration

Examine how key parameters influence outbreak dynamics:

# Systematic sensitivity analysis
sensitivity_params <- tidyr::expand_grid(
  beta_r = c(2, 4, 6, 8, 10),
  K_f = c(2, 4, 6, 8)
) |>
  mutate(scenario_id = paste0("beta", beta_r, "_Kf", K_f))

# Run models and calculate outbreak metrics
sensitivity_analysis <- sensitivity_params |>
  mutate(
    results = pmap(list(beta_r, K_f), ~ run_plague_model(
      scenario = "defaults",
      beta_r = ..1,
      K_f = ..2,
      n_particles = 30,
      years = 6
    )),
    metrics = map(results, ~ calculate_outbreak_metrics(.x, compartment = "I")),
    summary = map(metrics, summarize_outbreak_metrics),
    outbreak_prob = map_dbl(summary, ~ .x$outbreak_probability[1]),
    mean_peak = map_dbl(summary, ~ .x$mean_peak[1])
  )

# Visualize parameter sensitivity
ggplot(sensitivity_analysis, aes(beta_r, K_f, fill = outbreak_prob)) +
  geom_tile() +
  geom_text(aes(label = round(outbreak_prob, 2)), color = "white", size = 3) +
  scale_fill_viridis_c(name = "Outbreak\nProbability") +
  labs(title = "Parameter Sensitivity: Outbreak Probability",
       x = "Rat Infection Rate (beta_r)",
       y = "Flea Carrying Capacity (K_f)") +
  theme_minimal()

Parameter sensitivity analysis across key transmission parameters

Model Architecture Comparison

Compare dynamics across different model structures:

# Define different model configurations
model_configs <- list(
  "Single Population" = list(npop = 1, include_humans = FALSE),
  "Spatial (No Humans)" = list(npop = 16, include_humans = FALSE, K_r = 8000),
  "Single + Humans" = list(npop = 1, include_humans = TRUE),
  "Historical Parameters" = list(npop = 1, scenario = "historical", include_humans = FALSE)
)

# Run all model configurations
model_results <- imap(model_configs, ~ {
  args <- .x
  if (!"scenario" %in% names(args)) args$scenario <- "modern-estimates"
  args$n_particles <- 40
  args$years <- 8
  do.call(run_plague_model, args)
})

# Use built-in comparison plotting
plot_comparison(model_results, compartment = "I")

Comparison of model architectures

Equilibrium Analysis

Examine long-term system behavior:

# Calculate theoretical equilibria
# equilibrium_comparison <- param_sets |>
#   map(~ {
#     params <- load_scenario(.x)
#     eq <- calculate_equilibrium(params, model_type = "rats_only")
#     tibble(
#       parameter_set = .x,
#       R0 = eq$R0,
#       equilibrium_type = eq$equilibrium_type,
#       endemic_infected = ifelse(eq$equilibrium_type == "endemic", eq$I_r, 0)
#     )
#   }) |>
#   bind_rows()
#
# print(equilibrium_comparison)

Historical Applications

Black Death Modeling

Model medieval plague outbreaks with period-appropriate parameters:

# Historical plague with human transmission
results_black_death <- run_plague_model(
  scenario = "historical",
  include_humans = TRUE,
  npop = 1,
  n_particles = 60,
  years = 6
)

# Analyze human epidemic characteristics
human_outbreak <- results_black_death |>
  calculate_outbreak_metrics(compartment = "Ih") |>
  summarize_outbreak_metrics()

cat("Black Death Simulation Results:\n")
#> Black Death Simulation Results:
cat("===============================\n")
#> ===============================
cat("Human outbreak probability:", round(human_outbreak$outbreak_probability, 3), "\n")
#> Human outbreak probability: 1
cat("Mean peak human infections:", round(human_outbreak$mean_peak, 0), "\n")
#> Mean peak human infections: 1742
cat("Mean epidemic duration:", round(human_outbreak$mean_duration, 1), "years\n")
#> Mean epidemic duration: 0.6 years

# Plot multi-host dynamics
plot_dynamics(results_black_death, compartments = c("I", "Ih", "F"))

Black Death scenario with multi-host dynamics

Cross-Temporal Comparison

Compare historical vs modern plague dynamics:

# Compare different historical periods
historical_scenarios <- list(
  "Medieval (Black Death)" = "historical",
  "Early Modern" = "modern-estimates",
  "Contemporary" = "defaults"
)

historical_results <- map(historical_scenarios, ~ run_plague_model(
  scenario = .x,
  npop = 1,
  n_particles = 50,
  years = 5
))

# Professional comparison using built-in function
plot_comparison(historical_results, compartment = "I")

Historical vs modern plague transmission dynamics


# Quantitative comparison
historical_metrics <- historical_results |>
  imap(~ tibble(
    period = .y,
    outbreak_prob = .x |>
      calculate_outbreak_metrics(compartment = "I") |>
      summarize_outbreak_metrics() |>
      pull(outbreak_probability),
    R0 = calculate_R0(load_scenario(historical_scenarios[[.y]]))
  )) |>
  bind_rows()

print(historical_metrics)
#> # A tibble: 3 × 3
#>   period                 outbreak_prob    R0
#>   <chr>                          <dbl> <dbl>
#> 1 Medieval (Black Death)             1  596.
#> 2 Early Modern                       1  685.
#> 3 Contemporary                       1  582.

Public Health Applications

Control Intervention Analysis

Evaluate effectiveness of different plague control strategies:

# Define intervention scenarios
interventions <- list(
  "Baseline" = list(),
  "Vector Control" = list(K_f = 2.0),           # Reduce flea populations
  "Host Reduction" = list(K_r = 2000),          # Reduce rat populations
  "Enhanced Surveillance" = list(beta_r = 3.5), # Earlier detection/treatment
  "Combined Approach" = list(K_f = 2.5, K_r = 2500, beta_r = 4.0)
)

# Run intervention scenarios
intervention_results <- imap(interventions, ~ {
  args <- c(.x, list(scenario = "modern-estimates", n_particles = 50, years = 6))
  do.call(run_plague_model, args)
})

# Calculate intervention effectiveness
intervention_metrics <- intervention_results |>
  imap(~ {
    metrics <- .x |>
      calculate_outbreak_metrics(compartment = "I") |>
      summarize_outbreak_metrics()
    tibble(
      intervention = .y,
      outbreak_probability = metrics$outbreak_probability[1],
      mean_peak = metrics$mean_peak[1],
      outbreak_reduction = 1 - (outbreak_probability / intervention_metrics$outbreak_probability[1])
    )
  }) |>
  bind_rows()

# Calculate effectiveness relative to baseline
baseline_prob <- intervention_metrics$outbreak_probability[1]
intervention_metrics <- intervention_metrics |>
  mutate(effectiveness = (baseline_prob - outbreak_probability) / baseline_prob * 100)

print(intervention_metrics[c("intervention", "outbreak_probability", "effectiveness")])

# Visualize intervention effectiveness
plot_comparison(intervention_results, compartment = "I")

Spatial Risk Assessment

Assess outbreak risk across spatial landscapes:

# Risk assessment for spatial system
risk_spatial <- run_plague_model(
  scenario = "modern-estimates",
  npop = 25,
  K_r = 15000,
  n_particles = 100,
  years = 10
)

# Calculate population-specific risk metrics
population_risk <- risk_spatial |>
  filter(compartment == "I") |>
  group_by(population) |>
  summarise(
    max_infected = max(value),
    outbreak_frequency = mean(value > 5),
    mean_infected = mean(value),
    .groups = "drop"
  ) |>
  mutate(
    risk_category = case_when(
      outbreak_frequency > 0.5 ~ "High Risk",
      outbreak_frequency > 0.2 ~ "Moderate Risk",
      TRUE ~ "Low Risk"
    )
  )

# Visualize spatial risk
plot_spatial_heatmap(risk_spatial, time_point = 5, compartment = "I")

# Risk summary
table(population_risk$risk_category)

Early Warning Systems

Develop outbreak prediction based on force of infection:

# Calculate force of infection for early warning
foi_early_warning <- calculate_force_of_infection(risk_spatial)

# Identify high-risk time periods
warning_thresholds <- foi_early_warning |>
  group_by(population) |>
  summarise(
    mean_foi_rats = mean(lambda_r),
    peak_foi_rats = max(lambda_r),
    high_risk_periods = sum(lambda_r > quantile(lambda_r, 0.9)),
    .groups = "drop"
  ) |>
  arrange(desc(peak_foi_rats))

cat("Populations requiring enhanced surveillance (top 5):\n")
print(head(warning_thresholds, 5))

Summary

The yersinia package provides a comprehensive, professionally designed toolkit for plague transmission modeling that bridges theoretical epidemiology with practical public health applications.

Key Capabilities Demonstrated

Modeling Framework

Stochastic simulation: Captures demographic noise and extinction/recolonization dynamics missing from deterministic models
Multi-scale architecture: From single populations to complex spatial metapopulations with migration
Multi-host dynamics: Rat-flea-human transmission cycles with realistic biological parameters
Environmental forcing: Seasonal dynamics reflecting natural plague ecology

Professional Analysis Tools

Core functions: calculate_outbreak_metrics(), calculate_R0(), calculate_force_of_infection()
Stable plotting: plot() method and plot_comparison() for production use
Advanced visualization: Phase portraits, spatial heatmaps, and animations (provisional features)
Spatial analysis: Correlation matrices, spatial spread patterns, and metapopulation synchrony
Parameter exploration: Systematic sensitivity analysis and model comparison frameworks

Evidence-Based Parameters

Curated scenarios: Historical, contemporary, and research-validated parameter sets
Flexible customization: Runtime parameter modification without file editing
Literature integration: Direct implementation of parameters from key plague research

Real-World Applications

Public health planning: Control intervention assessment and effectiveness quantification
Risk assessment: Spatial risk mapping and early warning system development
Historical modeling: Black Death scenarios and cross-temporal epidemic comparison
Policy evaluation: Evidence-based assessment of surveillance and control strategies

Why Choose Stochastic Models?

Traditional deterministic models fail to capture: - Small population effects where random events drive dynamics - Spatial heterogeneity and local extinction/recolonization - Uncertainty quantification essential for policy decisions - Realistic outbreak variability observed in natural systems

The yersinia package addresses these limitations while maintaining computational efficiency and analytical rigor.

Getting Help & Further Resources

Function reference: help(package = "yersinia")
Main modeling function: ?run_plague_model
Parameter details: print() on loaded scenarios shows metadata and sources
Theoretical background: vignette("reference-deterministic-models") for deterministic comparisons

Key References

Keeling, M. J., & Gilligan, C. A. (2000). Metapopulation dynamics of bubonic plague. Nature, 407(6806), 903-906.
Stenseth, N. C., et al. (2008). Plague: past, present, and future. PLoS Medicine, 5(1), e3.
Bramanti, B., et al. (2019). Assessing the origins of the European Plagues following the Black Death. Proceedings of the National Academy of Sciences, 116(28), 13931-13940.

The yersinia package emphasizes reproducible, evidence-based modeling with professional-grade analysis capabilities for epidemiological research and public health decision-making.

Nicolas Gauthier

2025-09-10

Overview

Why Stochastic Models?

Key Features

Getting Started

Your First Plague Model

Built-in Plotting

Extracting Key Information

Evidence-Based Parameters

Curated Parameter Sets

Parameter Customization

Model Architecture

Single Population: Core Dynamics

Phase Space Analysis

Multi-Host Dynamics: Rats + Humans

Human-Specific Analysis

Spatial Metapopulations

Spatial Heat Maps (Provisional)

Animated Spatial Spread (Provisional)

Spatial Correlation Analysis

Environmental Seasonality

Advanced Analysis Toolkit

Reproduction Numbers and Invasion Analysis

Force of Infection Dynamics

Professional Outbreak Metrics

Parameter Sensitivity & Model Comparison

Systematic Parameter Exploration

Model Architecture Comparison

Equilibrium Analysis

Historical Applications

Black Death Modeling

Cross-Temporal Comparison

Public Health Applications

Control Intervention Analysis

Spatial Risk Assessment

Early Warning Systems

Summary

Key Capabilities Demonstrated

Modeling Framework

Professional Analysis Tools

Evidence-Based Parameters

Real-World Applications

Why Choose Stochastic Models?

Getting Help & Further Resources

Key References
